Commend GE 800 - Allocation of Licenses; Port-specific Licenses; Subscriber Bulk-Licenses

6. Licensing GE 800
30 1.1/1209
Allocation of Licenses:
1. Add the acquired licenses to the licence pool (see page 28)
2. Select the desired Server in the central area (2)
3. Drag-and-Drop the licenses onto the desired cards in the card area (3) (see page 28
)
4. At port-specific licenses the number of the interface port or subscriber must be entered in the field
Address (see ”
Port-specific licenses”)
5. After allocation of the licenses click Synchronize
Port-specific licenses
For the following licenses a port on the allocated card must be advised:
 ICX licenses (V24/ICX port)
 Intercom Client licenses (G8-IP port)
 ComWIN licenses (V24/ICX port)
 ComACCESS licenses (V24/ICX port)
 Allocate the licenses to the desired interface port / subscriber, by entering the last two digits of the
interface/subscriber address in the field Address („10“ in the example screenshot below).
Subscriber Bulk-Licenses
Subscriber bulk-licenses must be allocated to the respective subscriber cards in CCT. The licenses are
distributed in packs of 4 subscribers.
 Intercom Server > Subscriber features
 Activate the feature level upgrade by checking the box for the desired subscriber range (1-4 and/or
5-8) at the respective cards.
Note: If multiple TEMP SUB-28 Licenses are used, a separate number must be entered for each licence
in the field Address (see ”
Port-specific licenses”)!
Attention: The second interface (e.g.: 1/0-11) of the G8-GEP may NOT be used (this interface can
only be used for CCT-configuration).
