4. Strip the insulaon of the composite cable for 100 cm and the bers for 90 cm, and then shorten the
copper cables to 25 cm.
5. Insert the composite cable in the rst cable gland and separate the mul-bers cable from the copper
wires. It is necessary to remove the nut to perform this acon. The cable must be fed through the nut
and it must be reghtened once nished.
6. Bend the spliced bers using the corner guides and x the splices to the splice holder.
