Mount the Fiber CAP L
7 Insert an M8x16 screw in the top screw hole on the left Mounting Adapter attached to CAP L-1, and then
insert screw three or four turns.
M8x16 screw
M8x16 screw
Mounng
Adapter
Mounng
Adapter
8 Repeat Step 7 for the right Mounting Adapter.
