Refer to Health and Safety section before carrying
out any service work.
Page 80
CompAir Hydrovane
3G 230V 50/60Hz D.O.L. Standard Control Starter
Item Part Number Description Kit
Quantity
Starter Assembly No.
34424
1 74029 Contactor 1
2 74024 Terminal, double stack 3
3 74025 End section 2
4 74026 Transformer 1
5 56132 Fuse 1A 2
6 59344 OTC board 1
7 56122 Timer 1
8 53494 Timer base 1
9 74067 Knob operator (Auto) 1
10 74068 Indicator lamp (Reset) 1
11 72708 Push button (Start) 1
12 50432 Hours counter 1
13 72706 Emergency stop push button 1
14 74043 Power outlet socket 1
15 74039 Auxilary contact block 1
16 74064 Circuit breaker Q1F 1
17 74022 Terminal 5
18 74023 Earth terminal 1
19 74030 Thermal overload 1
20 74079 Connector, thermal overload 1
Starter assembly 34424 = 5.5 kW, 230 Volt, 50/60 Hz D.O.L. Standard Control
