5-46
ArmadaStation Removal and Replacement Procedures
5. Use a flat-blade screwdriver
1
to trip the C/U actuator
2
into the proper position by
pushing down on the actuator tab (Figure 5-44).
Figure 5-44.
Tripping the C/U Actuator
6. Install the screws securing the control panel assembly to the base assembly.
