Maintenance and Service Guide 7-13
3. Remove the four screws that secure the
power supply assembly to the chassis
(Figure 7-12).
Figure 7-12. Removing the Power Supply Screws.
4. Slide the power supply assembly toward
the drive housing assembly until the power
supply assembly is released from the tabs
holding it to the bottom of the chassis
(Figure 7-13).
Figure 7-13. Removing the Power Supply Assembly.
