Compaq DESKPRO 386 - SW2 Settings for the COMPAQ Enhanced

8-26 Chapter 8, Jumper Settings and Switch Settings
Configuration Switch Bank SW2
The setting for configuration switch bank SW2
is determined by the monitor type that you use
with the COMPAQ Enhanced Color Graphics
Board.
Table 8-16 SW2 Settings for the COMPAQ Enhanced Color Graphics Board
Configuration Switches
Monitor Type 1 2 3 4 5 6
COMPAQ Color, compatible Enhanced Color OFF OFF
RGBI Color ON OFF
COMPAQ Dual-Mode OFF ON
External RGBI enabled
Internal RGBI enabled (Portables)
ON
OFF
Reserved ON OFF ON
