1-18 Chapter 1, Operating and
Performance Specifications
1.17 300-/600-MEGABYTE FIXED DISK DRIVE EXPANSION UNIT
Dimensions:
Height:
Depth:
Width:
6.4 in. (16.1 cm)
16.5 in. (41.9 cm)
14.5 in. (35.9 cm)
Weight:
One Drive, 300-Megabyte unit:
Two Drives, 300-Megabyte units, mirrored:
27.5 lb (12.4 kg)
35.5 lb (15.9 kg)
Environmental Requirements:
Temperature
Operating:
Nonoperating:
Shipping (adequately packed):
Humidity:
Operating:
Nonoperating:
Not less than 50˚F or more than 104˚F (10˚C to 40˚C)
Not less than 50˚F or more than 104˚F (10˚C to 40˚C)
Not less than - 22˚F or more than 140˚F (- 30˚C to 60˚C)
Not less than 20% or more than 80% (noncondensing)
Not less than 5% or more than 90% (noncondensing)
Controller: 1:1 interleave Buffered ESDI External Fixed Disk Drive
Controller Board installs in one 8-/16-bit expansion slot in the
system unit.
Interface Board: Internal ESDI interface board supports one or two
300-Megabyte Fixed Disk Drives.
LED Indicator: Green
Power Requirements:
Nominal Line Voltage:
Range, Line Voltage:
Range, Line Frequency:
Power:
Steady State:
Peak Power:
U.S.
120 VAC, 60 Hz
102 to 132 VAC
47 to 63 Hz
192 watts
220 watts
International
230 VAC, 50 Hz
204 to 264 VAC
47 to 63 Hz
Current: (fuse rating) 5A (U.S.) 4A (International)
Power Cable:
Length:
Type:
Interface:
60 in (1.52 m)
44-Lead twisted pair
44-Pin Subminiature D-Shell
Signal Cable:
Length:
Type:
Connectors:
60 in (1.52 m)
44-Lead twisted pair
44-Pin Subminiature D-Shell
Addendum 108431-001 (11-88) to
Manual No. 108033-003
