Compaq ProLiant 3000 Setup And Installation Guide

4-6
Installing Hardware Options
For use with 350-MHz or greater Intel processor-based servers only
Writer: Cheri Stewart Project: Compaq ProLiant 3000 Servers Setup and Installation Guide Comments: 179776-002
File Name: E-CH04.DOC Last Saved On: 1/12/99 1:28 PM
COMPAQ CONFIDENTIAL - NEED TO KNOW REQUIRED
System Board Features Continued
Ref. Component
12
Secondary processor slot
13
CPU Fan header
14
Redundant CPU Fan header
15
Power connector
16
-
17
Power connectors
18
Power connector
19
IMD connector
20
Primary processor slot
21
Primary processor power module
22
Memory DIMM sockets 5-8
23
Floppy signal cable connector
24
Processor settings switch
25
IDE signal cable connector
26
I/O feature connector
27
Internal SCSI connector - SCSI Port 2
28
Internal SCSI connector - SCSI Port 1
29
I/O Fan header
30
Redundant I/O Fan header
31
System Configuration settings switch
