3-2 l Ins tal la tion
Unpacking the Boxes
The MDCW Carousel Plus Dryer comes in one to four boxes, depending on the
model and options ordered. The boxes could include (depending on the options
selected):
NOTE: * Depending on the model ordered, the vertical conveying tubes may be shipped
detached from the unit.
1 Carefully remove the dryer and components from their shipping containers,
and set upright. Note that the dryer is secured to its shipping container with
two bands and blocking.
2 Remove all packing material, protective paper, tape, and plastic.
3 Carefully inspect all components to make sure no damage occurred during
shipping, and that you have all the necessary hardware.
MDCW Dryer
Drying Hopper
Vertical Conveying Tubes*
Pump
Direct Feed
Vacuum Receiver
(Machine Loader)
Viewing Chamber and
Demand Sensor
Conveying
Filter
✐
DC-2 Control
Self-loading Hopper
Loader (Optional)
To Next Page
