4
Operation
Operati on l 4-11
Screen
SCREEN 1
SCREEN 2
SCREEN 3 (DEFAULT SCREEN)
CONAIR D100
CV2.21.00 DV2.21.00
MONDAY
07/22/03 07:59 AM
PROCESS TEMPERATURE
ACT 325°F SET 325°F
Control Function Descriptions
Function
Once power is turned on, this screen is
displayed for 3 seconds It shows CONAIR
and the dryer type on the first line, and the
control program version and display pro-
gram version on the second line.
Once power is turned on and screen 1 is
displayed for 3 seconds this screen is dis-
played for another 3 seconds. It shows the
day of the week on the first line and the
date and time on the second line. If this
information is not correct, it can be
changed under the SETUP, DISP, DATE
TIME screen 73.
This is the DEFAULT screen. It shows
the process air temperature setpoint and
actual temperature measured at the inlet to
the drying hopper. The setpoint can be
changed by pressing the Select Category
button under the Setpoint Value. Once the
button is pressed, the setpoint will begin
to flash. The numeric keys can be used to
enter a new setpoint or the (+) or (-)
Increment / Decrement buttons can be
used to change the setpoint. Holding the
(+) or (-) buttons in will allow the number
to ramp up faster the longer the button is
held. The “ENTER” key must be pressed
to accept the new number. The tempera-
ture setpoint range can be changed under
the
(continued)
NOTE: The supervisory pass-
word is required to change
certain parameters.
Additional information about
the password can be found
on Page 4-41 and on Page
4-32 under screen 85.
✐
To Next Page
