Operati on l 4-19
4
Operation
Function
Control Function Descriptions(continued)
Tip: This information is
important to know when
ordering a control board.
Tip: This information is
important to know when
ordering a display board.
✒
✒
Screen
SCREEN 30
SCREEN 31
SCREEN 32
SCREEN 33
SCREEN 34
MODEL CP150
480 V 60 Hz
DISPLAY FIRM V2.21.00
DISPLAY MENU V2.21.00
CONTROL FIRMWARE
VERSION V2.21.00
AUTOSTART COUNT DOWN
1 DAYS 23:05:53
AUTOSTOP COUNT DOWN
3 DAYS 11:04:23
This screen shows the model number, volt-
age, and frequency for which the dryer
control is setup. These values can be
changed with the proper password see page
4-32 (screen 85) under SETUP, OTHER,
INSP, Model # (screen 78), and Voltage
FREQ (screen 80).
This screen shows the current versions of
program for the Display Firmware and
Menus.
This screen shows the current versions of
program for the Control Firmware.
If the dryer is set with an auto start time,
this screen will appear and show the
amount of time remaining before the dryer
will automatically start. The LED on the
front of the display, beside the word Auto
Start, will flash if the dryer is set to start
automatically. The auto start feature can
be programmed under SETUP, PROC,
PROC, OTHER (screens 55, 56, 57). The
dryer can be set to automatically start and
stop each day.
If the dryer is set to auto stop, this screen
will appear and show the amount of time
remaining before the dryer will automati-
cally stop. The auto stop feature can be
programmed under SETUP, PROC,
PROC, OTHER (screens 55, 56, 57). The
dryer can be set to automatically start and
stop each day.
