131
OPTO READER Ref Sheet 17
Part Number - 772027
BCD1
BCD2
BCD4
ST
LU
DZ
LD
NOTES
Doors Closed - Lift Levelling Down in to Floor x x x
Lift Arrives at Floor x x x
Door Opening x x x
Doors Open x x x
Door Open Timer Off x x x
Doors Closing x x x
Doors Closed x x x
ST causes the hall and landing Displays to change
and makes the circuit for S on the floor Card. When
travelling down, the lift will stop at its destination
floor when the LD LED goes off.
FLOOR CARD May be T/B or Intermediate, Single or Dual Entrance
Front or Rear Opening is Jumper Selectable
See Jumper Selection Guide - Ref Sheets 100 to 103
*FCC
FC
LIMIT
S
FLOCK
SFC
*FHC
NOTES
Doors Closed - Lift Levelling Down in to Floor x
Lift Arrives at Floor x x x x
Door Opening x x x x
Doors Open x x x x
Door Open Timer Off x x x x
Doors Closing x x x x
Doors Closed x x
*FCC and *FHC - are momentarily lit when the Front
Car Call or Front Hall Call are pressed.
SFC is energized by S but the Door Contact on the
Landing gate must break for a hold path.
Remove any temporary jumpers.
On terminal floors, Limit is energized by NLD or
NLU.
SLIDING DOOR CONTROLLER Door Control - Slot T313 on Mother Board
Ref Sheet 43 - Part Number 772019
DOLF
DOF
DCLF
CLF
DOL
DOR
DCLR
CLR
DOP
DOT
DOL
SER
NOTES
Doors Closed - Lift Levelling Down in to Floor x x
Lift Arrives at Floor x x x x x
Door Opening x x x x x
Doors Open x x x x
Door Open Timer Off x x x x
Doors Closing x x x x
Doors Closed x x
OUTPUT BOARD Ref Sheet Numbers - 11 & 12
Part Number 772005
Doors
Closed
DCL
UDA
DOWN
Down
Pilot
DO1
NOTES
Lift Travelling Down at Low Speed x x x x x
Doors Closed - Lift Levelling Down in to Floor x x x x
Lift Arrives at Floor x x x
Door Opening x
Doors Open x
Door Open Timer Off x
Doors Closing x
Doors Closed
Only LED's Relevant to Door Operation are Shown
SLIDING DOOR OPERATOR Located on Door Operator
Ref Sheet Number 48
Part Numbers, Board - 772072, Microprocessor - 772023
OPEN
CLOSE
DCL2
DOL1
POWER
MS
DIR
RUN
DISPLAY
NOTES
Lift Travelling Down at Low Speed x x x x FH
Doors Closed - Lift Levelling Down in to Floor x x x x x F1
Lift Arrives at Floor x x x x x F1
Door Opening x x x x F3/F2
Doors Open x x x F
Door Open Timer Off x x x x F4
Doors Closing x x x F6/F5
Doors Closed x
To Next Page
