4
TOOLS AND MATERIALS REQUIRED
Standard Mechanics Tools to Include:
• Allen Wrenches (Keys) (1/8" - 3/8" Imperial)
• Screwdrivers (Slotted and Phillips)
• Set of Mechanical Sockets and Wrenches (1/4" - 1 1/4" Imperial Sizes)
• 3'-0" Carpenter’s Level and Square
• 3/8" Reversible Hand Drill (Variable Speed)
• Carbide Drill Bits, 3/8" (10 mm) and 1/2" (13 mm)
• 1/2" Hammer Drill (for concrete fasteners)
• Pry Bar
• Chain Hoist (required for higher travel units), minimum 1/2 ton capacity
• Hand Dolly
• Temporary Buttons
• Scratch Point Awl
• Plumb Bob and Line
• Chalk Line
• Tape Measure
• Wire Tie Wraps
• Wire Puller (50'-0" of 1/8" fish tape)
• Volt-Ohm Meter (V.O.M.)
• Stop Watch or Tachometer (to set final speed)
• Funnel (for filling the oil reservoir)
• Vise-Grip Pliers (standard and wide jaw welder’s type)
• Rags and Cleaning Solvent
• 100 ft. (30 m) Extension Cord (Minimum 14 gauge wire)
• 10" (250 mm) (Medium Cut) File (for filing joints, if required)
• Scaffolding or ladders and planks for erection of rails and brackets
• Wire Strippers
• Temporary Light for hoistway
• 1/2" Rope, minimum length to be as long as the hoistway height
• Rubber Mallet
Materials Required
• Lifting Sling (Cable or Nylon Strap of Adequate Strength)
• Coated Steel Shims, minimum 4" (100 mm) square
• Wall Anchors
• 10 Gauge and 14 Gauge Wire for motor and light wiring
• Assorted Butt Electrical Wire Connectors and Crimping Tool
• 32 Grade Hydraulic Oil, minimum 25 gal. (will vary depending on travel)
• 1/2" Electrical Box Connectors
• Shaft Wiring Materials (varies depending on local codes). 20 gauge stranded multi-wire
cable with 11 conductors for connection from landings to halfway box (from Concord)
NOTE
There may be additional tools required to complete your installation.
