GENERAL SPECIFICATIONS
SPECIFICATION CONCORD HORIZON ELEVATOR
Load Capacity 1,400 lbs. (635 kg)
Rated Speed 30 feet per minute (0.15 m/s)
Power Supply 208 volt, 3 phase or 220 volt, single phase, 30 amps.
Drive System 1:2 Cable Hydraulic
Cab Size 48" Wide x 54" Depth (1220 mm x 1372 mm) or
54" Wide x 48" Depth (1372 mm x 1220 mm)
Door Opening 36" x 80" (890 mm x 2030 mm) nominal
Maximum Travel 30 feet (9.14 m)
Overhead Clearance 110" (2794 mm) or
131" (3327 mm) when refuge space is required
Max. Number of Stops 4
Pit Depth Required 14" (356 mm)
Control System Non-Selective Collective
Floor Selection Optical Sensor
Control Panel Finish Stainless Steel
Call Station Finish Stainless Steel
Hall Station Finish Stainless Steel
Flooring Material Plywood with Rubber Non-Skid Sheeting
Lighting Supply 110 volt, 60 cycle, 15 amps.
Standard Features
• Emergency Battery Powered Lowering
• Automatic Emergency Lighting
• Automatic Timed Car Lighting
• Emergency Lowering Valve at Pump
• Anti-creep Releveling Device
• Slack/broken Cable Safety Device
• Upper and Lower Limit Switches
• Final Limit Switch
•
Stainless Steel Handrail
•
Digital Floor Indicator in cab
• “Car In Use” Illuminated Hall Buttons
• In Car Directional Indicators
• Tactile Plates
