Continental Fireplaces CB36PTR - Top Exit Horizontal Termination

17
3.8
top exit horizontal termination
(H
T
) < (V
T
)
EN
Simple venting configuration (only one 90° elbow)
See graph to determine the required vertical
rise V
T
for the required horizontal run H
T
.
40 (12.2)
39 (11.9)
REQUIRED
30 (9.1)
VERTICAL
RISE IN FEET
20 (6.1)
(METERS) V
T
10 (3.1)
0
2.5
5
7.5
10
12.5
15
17.5
20
(0.8)
(1.5)
(2.3)
(3.1)
(3.8)
(4.6)
(5.3)
(6.1)
HORIZONTAL VENT RUN PLUS OFFSET IN FEET
(METERS) H
T
The shaded area within the lines represents
acceptable values for H
T
and V
T
For vent configurations requiring more than one 90° elbow, the following formulas apply:
Formula 1: H
T
<
V
T
<
Formula 2: H
T
+ V
T
40 feet (12.2m)
Example:
V
1
= 3 FT (0.9m)
V
2
= 8 FT (2.4m)
V
T
= V
1
+ V
2
= 3 FT (0.9m ) + 8 FT (2.4m) = 11 FT (3.4m)
H
1
= 2.5 FT (0.8m)
H
2
= 2 FT (0.6m)
H
R
= H
1
+ H
2
= 2.5 FT (0.8m) + 2 FT (0.6m) = 4.5 FT (1.4m)
H
O
= .03 (three 90° elbows - 90°) = .03
(270° - 90°) = 5.4 FT (1.7m)
H
T
= H
R
+ H
O
= 4.5 FT (1.4m) + 5.4
FT (1.6m) = 9.9 FT (3m)
H
T
+ V
T
= 9.9 FT (3m) + 11
FT (3.4m) = 20.9 FT (6.4m)
Formula 1:
H
T
<
V
T
< 11 FT (3.4m)
9.9 FT (3m)
Formula 2:
H
T
+ V
T
<
40 FT (12.2m)
20.9 FT (6.4m) < 40 FT (12.2m)
Since both formulas are met, this vent confi guration is acceptable.
90°
H
2
V
2
90°
90°
H
1
V
1
W415-1679 / D / 03.09.18
