Control Techniques Dinverter A User Manual

Dinverter A User Guide
Issue code: d2au9
21
Mounting the Drive on a DIN-rail
1 Allow clearances around the Drive. Make a threaded hole for securing
the Drive to the back-plate
≥5mm
(¼ in)
≥5mm
(¼ in)
75mm (3 in)
36mm
(1 /
8
in)
108mm
(4¼ in)
≥100mm
(4 in)
≥100mm
(4 in)
140mm
(5½ in)
DIN-rail
Area occupied
by the Drive
Surface-mounting
bracket
Nearest objects
to the Drive
∅ M5
( /
16 in)
3
3

Control Techniques Dinverter A Specifications

General

Brand	Control Techniques
Model	Dinverter A
Category	Servo Drives
Language	English
