4.5 Wiring recommendations
Caution
When the motor phase connections are made (U-to-U,
V-to-V, W-to-W) and a RUN FORWARD command is given to
the Drive, the motor runs in the reverse direction
(anticlockwise rotation as seen from the shaft-end of the
motor). To make the motor run in the opposite direction,
exchange two of the phase connections.
Observe the wiring recommendations given in this section. The details of
individual installations may vary, but details which are indicated in the
recommendations to be important for EMC must be adhered to closely.
When external signal connections are to be made to the Drive, also refer to
Signal connections for operation in Terminal mode later in this chapter.
