Control Techniques Dinverter A User Manual

Dinverter A User Guide
Issue code: d2au9
34
Front gland
Output connections
(to the Drive)
Rear gland
Input connections
(from the AC supply)
Figure 4–7 Assignments of the glands (when used) in the terminal chamber
of the RFI filter
3 If required, fit two glands to the gland plate.
4 Make the connections shown in Figure 4–9.
5 If required, connect terminal D1 to terminal D2 to set the RFI filter in
long-cable mode.
