6.2 Configuring the Drive for the motor
Warning
The values of the motor parameters affect the protection
of the motor and the safety of the system.
Caution
When entering values, make sure they are relevant to the
motor that is to be used. The default values in the Drive
should not be relied upon.
The motor parameters should be set to within 10% of the
required values for the motor. Failure to do this may result
in poor response.
Keep a note of the values given to the motor parameters,
since motor parameters are restored to their default values
when the Restore to default values function is used. After
restoring parameters to their default values, and before
starting the Drive, re-enter the appropriate values for the
motor parameters.
Check that the motor current-rating applies to the winding configuration
used (typically 220V delta-wound). Enter the motor current-rating in
parameter 0.46 Motor – rated current.
Table 6–1 Maximum continuous current
Model I
max
DIN1220025A 1.5A
DIN1220037A 2.3A
DIN1220055A 3.0A
DIN1220075A 4.3A
Note
It is essential that the correct value is entered in
parameter 0.46. This affects the thermal protection of
the motor.
