page-16 EVOLUTION COVER
PART IMAGE FUNCTION
Jack
Jacks are a very important component of the cover. They
allow the cover to lift up and down.
Operator
The operator powers and controls the lifting mechanism
of the cover.
Sleeve
The sleeves are aluminum extrusions to hide and protect
the jacks.
U-frame
The U-frames protect the lifting mechanical components
and connect all four posts at the bottom.
Jack lock screw (A)
The jack lock screw (A) prevents the non-motor side
jacks from extending. Do not remove this screw until the
driving shaft is connected.
Follow installation steps carefully.
A: Jack lock screw
B: Top plate screw
C: Bushing
D: Alignment bracket (red)
