Supply/RF Board Components
Service Parts
Force FX Electrosurgical Generator C Service Manual 9-23
C40 18000 pF ± 5%, 500 V 1042271
C41, C60 15000 pF ± 5%, 500 V 1042272
C42 1500 pF ± 5%, 100 V 1042273
C54, C81,
C104
.47 µF ± 20%, 50 V 1042250
C63 22 pF ± 5%, 100 V 1042293
C59, C66,
C67, C69,
C76, C77,
C85, C100,
C101
CAP CER 0.1 µF 100 V 10% X7S SMD 0603 1078183
C73 33 pF ± 5%, 100 V 1042307
C107 1000 pF ± 5%, 100 V 1042257
C105, C108 .047 µF ± 20%, 50 V 1042247
C119, C126,
C129
6800 pF ± 5%, 100 V 1042326
C150, C151,
C158, C159
3900 pF ± 5%, 500 V 1042309
C152 3300 pF ± 5%, 500 V 1042306
C154, C157 .0047 µF ± 10%, 2000 V 1042244
C155, C169 .68 µF, 100 V 1042251
C171 10 µF ± 20%, 25 V 1042266
C174 470 pF ± 5%, 100 V 1042314
C111, C112,
C175, C176,
C177, C178,
C179, C180,
C185
CAP MICA 30 PF 100 V 5% SMD 0805 1078179
C68 CAP CER 22 PF 100 V 5% COG SMD 0603 1078284
C75 CAP CER 33 PF 100 V 5% NPO SMD 0603 1078285
Reference
Designator Description Part Number
