Supply/RF Board Components
9-24 Force FX Electrosurgical Generator C Service Manual
C79 CAP CER 1000 PF 100 V 5% COG 0603 1078286
Diodes
CR1 1N4007 1042283
CR3, CR4,
CR5, CR6,
CR7, CR8,
CR12, CR15,
CR25, CR26,
CR27, CR28,
CR34, CR37,
CR39, CR41
1N4148 1042284
CR9 LED, GREEN, 2 DIA. 1041644
CR14, CR16,
CR29
SCHOTTKY 0.6 A, 40 V 1042365
CR20, CR21,
CR22, CR24,
CR32, CR36,
CR38, CR40,
CR51
ZENER 1N5240B, 10 V 1042286
CR33, CR42,
CR44, CR45,
CR46, CR52
ZENER 1N5233B 1042285
CR17, CR18,
CR47, CR48,
CR49, CR50
DIODE SWITCH 100 V 0.15 A SOD 123 1078289
Fuses
F1, F2, F3 FUSE, SUB-MINI 1/2 A 1049716
F4 FUSE, 5 x 20 mm, 6.3 A 1042348
Relays
K1, K3, K4,
K5, K6, K8,
K9, K10, K11
12 V 1042361
K2 6-POLE 1042362
Reference
Designator
Description Part Number
