Supply/RF Board Components
Service Parts
Force FX Electrosurgical Generator C Service Manual 9-25
K7 RELAY 1042364
K12, K13,
K14, K15,
K16, K17
COTO-9442 1042363
Transistors
Q2 FET N-CH 14 A, 60 V 1042979
Q6, Q8, Q9,
Q10
FET TN2404KL 1042981
Resistors
R1, R2 9.1 K
, 1 W 1042332
R3, R38, R69 1 M
 ± 5%, 1/4 W 1042282
R4 18.2 K
 ± 1%, 1/8 W 1042276
R5, R6 30 K
 ± 5%, 3 W 1042305
R7 91 K
 ± 5%, 1/4 W 1042333
R8, R169 390
 ± 5%, 1/4 W 1042235
R9 10
 ± 5%, 1 W 1042255
R10 63.4 K
 ± 1%, 1/4 W 1042325
R11, R17,
R20, R25,
R39, R75,
R79, R92,
R101, R106,
R170
1 K
 ± 5%, 1/4 W 1042278
R12, R18,
R21, R26,
R131, R136,
R140
51
 ± 5%, 1/4 W 1042233
R74, R81,
R87, R180,
R181
RES 0603 1.00 K
1% SMD 1078294
Reference
Designator Description Part Number
