Covidien Force FX - Page 241

Supply/RF Board Components
Service Parts
Force FX Electrosurgical Generator C Service Manual 9-27
R121, R182,
R183, R184,
R185, R187,
R188, R189,
R190, R191,
R192, R193,
R194, R195,
R196
RES THICK FILM 0603 100
1% SMD 1078166
R70, R125,
R126, R128
RES 0603 4.70 K
 1% SMD 1078292
R41 649
 ± 1%, 1/8 W 1042279
R42, R55,
R151, R156,
R158, R162,
R163, R165
10 K
 ± 1%, 1/4 W 1042263
R95 RES 0603 10.0 K
1% SMD 1078300
R43, R104 68 K
 ± 5%, 1/4 W 1042329
R44 5.6 M
 ± 5%, 1/4 W 1042319
R46 330
 ± 5%, 1/4 W 1042234
R47 1.6 K
 ± 5%, 1/4 W 1042253
R49, R53 2.67 K
 ± 1%, 1/8 W 1042290
R50 511
 ± 1%, 1/2 W 1042321
R56 200 K
 ± 5%, 1/4 W 1042291
R57, R66 110 K
 ± 5%, 1/4 W 1042267
R58 39 K
 ± 5%, 1/2 W 1042310
R59, R60,
R63, R65
2 K
 ± 1%, 1/8 W 1042298
R61, R64 1 K
 ± 1%, 1/8 W 1042280
R62 499
 ± 1%, 1/8 W 1042315
R68 510
 ± 5%, 1/4 W 1042236
Reference
Designator Description Part Number
