Supply/RF Board Components
9-28 Force FX Electrosurgical Generator C Service Manual
R76 100  ± 1%, 2 W 1042256
R77 221
 ± 1%, 1/8 W 1042292
R78 280
 ± 1%, 1/4 W 1042297
R71, R72,
R73, R85
RES 0603 2.00
1% SMD 1078293
R82 RES 0603 499
1% SMD 1078295
R80 62 K
 ± 5%, 1/4 W 1042324
R83, R84 RES 0603 249
1% SMD 1078296
R88 RES 0603 6.80 K
1% SMD 1078297
R89 RES 0603 5.10 K
1% SMD 1078298
R90 RES 0603 3.92 K
 1% SMD 1078299
R94 56.2 K
 ± 1%, 1/8 W 1042322
R96 TRIMPOT, 5 K
 1042299
R97 RES 0603 301
1% SMD 1078302
R98 THERMISTOR, 1 K /25C 5% 1042281
R103 47
 ± 5%, 1/4 W 1042232
R105, R141 100 K
 ± 5%, 1/4 W 1042258
R110 2.15 K
 ± 1%, 1/8 W 1042289
R113, R114,
R115,
820
 ± 5%, 1/4 W 1042238
R120 3.40 K
 ± 1%, 1/8 W 1042303
R123 270 K
 ± 5%, 1/4 W 1041641
R124, R144,
R146, R147,
R152, R155
750
 ± 5%, 1/4 W 1042237
R139 93.1 K  ± 1%, 1/4 W 1063247
Reference
Designator Description Part Number
