Supply/RF Board Components
Service Parts
Force FX Electrosurgical Generator C Service Manual 9-29
R138 15.0 K  ± 1%, 1/4 W 1042274
R145, R154,
R157, R161,
R167
5.11 K
 ± 1%, 1/8 W 1042317
R148, R149 10 K  ± 1%, 10 W 1042264
R186 RES 0603 10.0
1% SMD 1078303
R116, R129,
R172, R174,
R175, R176,
R177, R178,
R179
VARISTOR 24 V 0603 1078180
R150, R153,
R159, R166,
R168
4.32 K
 ± 1%, 1/8 W 1042311
R160, R164 5.6 M  ± 10%, 2 W 1042320
Transformers
T1 PULSE, DUAL 1049710
T2, T6, T8,
T16, T17
INDUCTOR, CURRENT SENSE 1042984
T3 POWER SWITCHING 1049709
T4 RF, MOLDED 3F3 CORE 1049713
T7, T10, T11,
T12
SQUARE CORE, REM 1051726
T13 VOLTAGE SENSE 1049711
T14, T15 RF CHOKE 1049704
Integrated Circuits
U32-U34 DIFF COMPARATOR QUAD 14 SOIC 1049744
U1 AVS1AC 1042976
U2, U9, U20,
U26
LM 393 N 1042353
Reference
Designator Description Part Number
