U3, U13, U19 MOSFET DRIVER TSC1427 1042239
U4 MOSFET DRIVER 1042355
U5 PWM CONTROLLER, HIGH SPEED 1049749
U6 QUAD 2 INPUT 4093B 1042241
U7 OP-AMP MAX 492CPA 1042354
U8, U10,
U11, U12,
U23
DUAL OP-AMP AD827 1042334
U14 MULTIVIBRATOR 74LS221 1042242
U15, U16 2803A 1041652
U18, U21 OP-AMP LF412 1042351
U24 LM319 1042352
U25, U31 OP-AMP TL052A 1042368
U28 QUAD ANALOG SWITCH 1049743
U29 4081 1042240
U30 IC HEX INV 74 HC14 1042331
U22 IC ANALOG MUX W/DIODES 1042346
Miscellaneous
D1 THERMISTOR TRIAC AVS 12 CB 1042974
J1 PHONE JACK 1042360
J2 CONNECTOR 15 PIN R/A 1042343
J3 CONNECTOR 90 DEG PCB 9 PIN 1042344
J5 CONNECTOR HEADER VERT 20 POS .100 GOLD 1078290
J6 CONNECTOR PCB 5 CKT 1042357
J7 CONNECTOR PCB 6 CKT 1042358
J8 CONNECTOR PCB 7 CKT 1042366
J9 CONNECTOR PC EDGE 1042340
Reference
Designator Description Part Number
9-30 Force FX Electrosurgical Generator C Service Manual
