Covidien Force FX - Page 245

Supply/RF Board Components
Service Parts
Force FX Electrosurgical Generator C Service Manual 9-31
J10 CONNECTOR PCB 8 CKT 1042359
J16 CONNECTOR PCB 4 CKT 1042338
J12 CONNECTOR PCB 3 CKT 1042356
J13 CONNECTOR 96 PIN 1042339
J15, J4 CONN-PC MALE 1042336
J17 CONNECTOR PCB 2 CKT 1042337
J18, J19 CONTACT MONOPOLAR 1051136
J20 BIPOLAR CONTACT SPRING 1049707
J21, J22, J23,
J24, J25, J26,
J27, J28
FUSE CLIP 1042983
J29, J30 CONN HEADER VERT 4 POS .100 TIN 1078291
FB1, FB2, FB3,
FB4, FB5, FB6,
FB7, FB8, FB9,
FB10, FB11,
FB12, FB13,
FB14, FB15,
FB16, FB17,
FB18, FB19,
FB20, FB21
FERRITE 3A 100
1206 SMD 1078178
L1 INDUCTOR, 0.75 MH 1049708
OPT1, OPT2,
OPT3, OPT4,
OPT5
OPTOISOLATOR, SINGLE 1049745
TP1, TP2, TP3,
TP4, TP5,TP6,
TP7, TP8, TP9,
TP10, TP11,
TP12, TP13,
TP15,TP16,
TP17, TP18,
TP19
TEST POINT 1049705
U17 OSCILLATOR, PRECISION 1049736
Reference
Designator Description Part Number
