CPS ECB200KTL/US-800 - Technical Data

Technical Data
130 / 135
9 Technical Data
Model Name
CPS ECB200KTL/US-800
DC Input
Max. DC Input Voltage
1500V
Min. DC Input Voltage
875V
Operating DC input Voltage
Range (1)
950-1500V (45°C)
Max. DC Input Current
218A
DC Disconnection Type
Load-rated DC Switch
DC Surge Protection
Type II
AC Output
Rated AC Output Power @
PF>0.99
200kVA / 200kW @ 45°C 170kVA / 170kW
@ 50°C
Rated Output Voltage
800Vac
Output Voltage Range (4)
704-880Vac
Grid Connection Type
3-Phase / PE
Max. AC Output Current @
800Vac
145A
Nominal Grid Frequency / Grid
Frequency Range
60 Hz / 55 – 65 Hz
Adjustable Reactive Power
-100% to +100%
AC Current THD
< 3% (at nominal power)
DC Current Injection
< 0.5% Inom.
Max. OCPD Rating
285A
AC Surge Protection
Type II
System and Performance
Max. Efficiency
98.0%
CEC Efficiency
97.0%
Stand-by Consumption
<30W
Environment
Enclosure Protection Degree
NEMA Type 4X
Cooling Method
Variable speed cooling fans
Operating Temperature Range
(2)
-22°F to +140°F/ -30°C to +60°C (derating
from +113°F / +45°C)
Operating Humidity
0 to 100%
Operating Altitude (3)
9842.5ft / 3000m (no derating)
Display and
Communication
User Interface and Display
LED indicators, WiFi + APP
PCS Monitoring
CAN/ Ethernet/RS485
