Mechanical Installation
13 / 135
3 Mechanical Installation
3.1 Unpacking for Inspection
Below is the installation procedure for the PCS. Please read carefully and install the
product step-by-step.
Before installation, please check that the following items are included in the package.
Table 3-1 Main items
No.
Item
Qty
Note
1
CPS ECB200KTL/US-800
1
PCS
2
Accessory kit
1
Contains all necessary accessories
The Accessory Kit contains items listed below.
Table 3-2 ECB200KTL Accessories
No.
Item
Qty
Note
(1)
10-pin terminal
4
For Communication cables
(2)
4-pin terminal
1
For output dry node cable
(3)
M6X16 screw, Grade: A2-50
8
For fastening PCS
(4)
95mm
2
Connector, black
4
For DC- and L1,L2,L3 cable
connection
(5)
95mm
2
Connector, orange
1
For DC+ cable connection
(6)
LINKIT (Optional)
/
For Wi-Fi communication
3.2 Installation Precautions
 Check that the product environmental specifications (protection degree,
operating temperature range, humidity and altitude, etc.) meet the
requirements of the specific project location;
 Make sure that the power grid voltage is within allowed range: 422~528 VAC;
 Ensure that the local electricity supply authority has granted permission to
connect to the grid;
 Installation personnel must be qualified electricians or people who have
received professional training;
 Wear and use PPE (personal protective equipment) during installation and
cable connection, such as safety shoes, safety gloves, safety helmet, etc.
INSTRUCTION:
The items in the accessory kit table above are for the standard
configuration.
