Commissioning
37 / 135
5 Commissioning
WARNING:
Please follow the guidelines below before on-grid operation to
eliminate possible dangers to ensure safety.
5.1 Pre-commissioning Checklist
Make sure that the PCS is installed properly
according to the previous sections.
Make sure all the screws have been tightened
to the specified torque values.
(Please refer to Section 3 Mechanical
installation)
Make sure that all cables are connected to the
terminals properly.
Use appropriate cable management to avoid
physical damage.
The polarity of DC input cables should be
correct
AC output cables should be correct (Please
refer to 4 Electrical installation)
Test whether the AC voltage is within the
normal operating range.
Make sure the DC open circuit voltage of input
Battery is less than 1500V.
Table 5-1 Pre-commissioning Checklist
5.2 Commissioning steps
Complete the checklist above before commissioning the PCS as follows:
1. Turn on the DC Switch.
2. When the energy supplied by the Battery is sufficient, the LED of PCS will
light up. The PCS will start up then.
3. Set up the PCS according to section 6.2 Mobile application functions or
section 6.3 Web application functions.
