Mechanical Installation
19 / 135
(2) Use two ropes to lift the device with the aid of aforementioned eyebolts
and the two lifting holes on the front mounting bracket, see figure 3-9 for
details.
Figure 3-9 Rope lifting with eyebolts and lifting holes
NOTICE:
The length of ropes shall make sure the angle between two sling
ropes is less than 60 degree, thus avoiding to damage or bend the
enclosure edges.
Consult the after-sale personnel for any special scenarios.
 Hoist the bottom of the PCS with forklift
(1) Find the center of gravity of the PCS as shown below.
Figure 3-10 Center of gravity of the PCS
