User Interface
70 / 135
Refer to table 6-6 below for information about the parameter description, setup range,
lower limit, default and upper limit of these parameters.
Table 6-6 HVRT and LVRT Parameters
Parameter name
Description
Setup range (lower limit,
default, upper limit)
IEEE1547-2018
LVRTOption
LVRT enable/disable
{Enable}
LVRTTripVol
Trigger voltage of LVRT
{0,83.0%,100.0%}
FVRTPosCurrK
Coefficient of reactive current in positive
sequence
{0,1.5,5.0}
FVRTNegCurrK
Coefficient of reactive current in negative
sequence
{0,2.0,5.0}
HVRTOption
HVRT enable/disable
{ Enable}
HVRTTripVol
Trigger voltage of HVRT
{100.0%,110.0%,130.0%}
FVRTPowerStep
Power step in LVRT or HVRT
{0.10%,100.01%,100.01%}
