Refer to table 6-7 below for information about the parameter description, setup range,
lower limit, default and upper limit of these parameters.
Table 6-7 Battery Parameters
Parameter name
Description
Setup range (lower limit,
default, upper limit)
IEEE1547-2018
ChargeVoltLimt
Battery charging voltage limit
{875.0,950.0,1550.0 V}
DisChargeVoltLimt
Battery discharge voltage limit
{875.0,875.0,1550.0 V}
ChargeCurrLimt
Battery charging current limit
{-220.0, -220.0, 0.0 A}
DisChargeCurrLimt
Battery discharge current limit
{0.0, 220.0, 220.0 A}
FloatChargeVolt
Set the battery floating charge
voltage
{875.0,950.0,1550.0 V}
SToFChargeCurr
Set the battery floating charging
current
{-220.0, -10.0, 0.0 A}
BatteryVoltMax
Battery voltage upper limit
{875.0,1550.0,1600.0 V}
BatteryVoltMin
Battery voltage lower limit
{800.0,865.0,1550.0 V}
BatChargeCurrMax
Battery charging current protection
point
{-400.0, -300.0, 0.0 A}
BatDisChargeCurrMax
Battery discharge current
protection point
{0.0, 300.0, 400.0 A}
DCRelayVoltDiff
DC relay closing voltage difference
{0.0, 15.0, 30.0 V}
BatPreChargeCurrMax
Battery precharge current Max.
value
{-400.0, -300.0, 0.0 A}
