User Interface
75 / 135
Refer to table 6-8 below for information about the parameter description, setup range,
lower limit, default and upper limit of these parameters.
Table 6-8 Other Parameters
Parameter name
Description
Setup range (lower limit,
default, upper limit)
IEEE1547-2018
InvCurrMax
Max. PCS current
{0.0,188.00,200.00A}
DCIOffsetDiffMax
Permissible upper limit of DCI
offset differential
{0,500,682}
OffsetDiffMax
Upper limit of PCS current offset
{0,100,256}
EnvironmentTmpMax
Upper limit of ambient
temperature
{0.0,60.0,90.0℃}
InvModuleTmpMax
Upper limit of PCS module
temperature
{0.0,103.0,120.0℃}
BstModuleTmpMax
Upper limit of Boost module
temperature
{0.0,96.0,120.0℃}
OutBoardTmpTmpMax
Upper limit of output board
temperature
{0.0,85.0,120.0℃}
BusVolMax
Upper limit of Bus voltage
{1000.0,1550.0,1600.0V}
CapVolMax
Upper limit of half Bus voltage
{520.0,825.0,850.0V}
DCRelayActProt
Disconnect protection
enable/disable of DC relay in
fault status
{Enable}
RemoteSel
Remote control selection
enable/disable
{Disable}
BatteryType
Battery type selection
{Li battery}
DcvCtrlEnnable
DCV control enable/disable
{Disable}
WaveRecEn
Wave recording enable/disable
1
