User Interface
81 / 135
Refer to table 6-10 below for information about the parameter description, setup
range, lower limit, default and upper limit of these parameters.
Table 6-10 Source mode Parameters
Parameter name
Description
Setup range (lower limit,
default, upper limit)
IEEE1547-2018
CSVSSwitch
Current source and voltage source
mode Switch
{CS}
CSVSAutoSwitchEn
Power grid synchronization
enable/disable
{Disable}
VSCtrMode
VS Control mode
{Disable}
VSVoltSet
VS voltage setting
{700.0,800.0,960.0v}
VSFreqSet
VS frequency setting
{40.0,50.0,70.0Hz}
VSPSet
VS active output setting
{-100.0%,0.0%,100.0%}
VSQSet
VS reactive power output setting
{-100.0%,0.0%,100.0%}
VSDroopEn
VS Droop control enable/disable
{Enable}
VSPCtrlFreK
Active power - frequency control factor
{20,100,400}
VSQCtrlUK
Reactive power - voltage control
coefficient
{50,100,800}
VSVirtualL
Virtual lightning resist
{0.0,3.04,5.00mH}
VSVirtualR
Virtual resistance
{0.10,0.40,1.00 ohm}
