Table 6-11 Source mode Parameters
Parameter name
Description
Setup range (lower
limit, default, upper
limit) IEEE1547-2018
wRemoteCSVSSwitch
Remote control mode switch: CS/VS
{CS}
wRemoteVSCtrMode
Remote VS control mode
{Disable}
wRemoteVSFreqSet
Remote control VS frequency setting
{40.0,50.0,70.0Hz}
wRemoteVSVoltSet
Remote control VS voltage setting
{700.0,800.0,960.0v}
wRemoteCSPCtrEn
Remote CS active power control
enable/disable
{Enable}
wRemoteCSPCtrModeSel
Remote CS active control mode
selection: active value mode/ DC
current mode
{Active power mode}
wRemoteCSPPer
Remote CS active power percent
{-120.0%,0.0%,120.0%}
wRemoteCSCurrSet
Remote CS DC current setting
{-225.00,0.00,225.00A}
wRemoteCSQCtrEn
Remote CS reactive power control
enable/disable
{Disable}
wRemoteCSQCtrModeSel
Remote CS reactive power control
mode selection: PF mode/ Given Q
mode
{Given Q mode}
wRemoteCSPFSet
Remote PF Settings
{-1.000,1.000,1.000}
wRemoteCSQPer
Remote reactive power percent
{-100.0%,0.0%,100.0%}
wRemoteK7Ctr
Remote K7 switch control
{Connect}
fRemotePCSComdOn
Remote PCS power on/off command
{Power off}
wRemoteVSPSet
Remote VS active power output setting
{-100.0%,0.0%,100.0%}
wRemoteVSQSet
Remote VS reactive power output
setting
{-100.0%,0.0%,100.0%}
