User Interface
88 / 135
Refer to table 6-13 below for information about the parameter description, setup
range, lower limit, default and upper limit of these parameters.
Table 6-13 QP/QU Function Setting Items
Parameter name
Description
Setup range (lower limit,
default, upper limit)
IEEE1547-2018
Q_PCurveP1s
Power of Q_P Curve point 1s
{0,20.0%,70.0%}
Q_PCurveQ1s
Reactive power of Q_P Curve point 1s
{-100.0%,0,100.0%}
Q_PCurveP2s
Power of Q_P Curve point 2s
{40.0%,50.0%,80.0%}
Q_PCurveQ2s
Reactive power of Q_P Curve point 2s
{-100.0%,0,100.0%}
Q_PCurveP3s
Power of Q_P Curve point 3s
{50.0%,100.0%,100.0%}
Q_PCurveQ3s
Reactive power of Q_P Curve point 3s
{-100.0%,-44.0%,100.0%}
Q_PCurveP1i
Power of Q_P Curve point 1i
{-70.0%,-20.0%,0}
Q_PCurveQ1i
Reactive power of Q_P Curve point 1i
{-100.0%,0,100.0%}
Q_PCurveP2i
Power of Q_P Curve point 2i
{-80.0%,-50.0%,-40.0%}
Q_PCurveQ2i
Reactive power of Q_P Curve point 2i
{100.0%,0,100.0%}
Q_PCurveP3i
Power of Q_P Curve point 3i
{-100.0%,-100.0%,-50.0%}
Q_PCurveQ3i
Reactive power of Q_P Curve point 3i
{-100.0%,44.0%,100.0%}
QPActTime
QP curve action time
{0,5.00s,10.00s}
Q_UCurveVRef
QU curve Vref
{95.0%,100.0%,105.0%}
Q_UCurveVRefEn
QU curve Vref auto adjust
enable/disable
{Enable}
Q_UCurveVRefTime
QU curve Vref adjust time constant
{300,300,5000s}
Q_UCurPowPrio
QU curve power priority: Reactive power
first/ Active power first
{Reactive power first}
