Stand-by / Night Consumption
Enclosure Protection Degree
Variable speed cooling fans
Operating Temperature Range
3
-22°F to +140°F / - 30°C to +60°C (derating from +113°F / +45°C)
Non-Operating Temperature
Range
4
No low temp minimum to +158°F / +70°C maximum
13,123.4ft / 4000m (derating from 9842.5ft / 3000m)
Display and Communication
User Interface and Display
CPS FlexOM Gateway (1 per 32 inverters)
Remote Diagnostics / FW
Upgrade Functions
Standard / with FlexOM Gateway
39.4 x 23.6 x 10.24 in. (600×1000×260mm)
Inverter:123.5lbs/56kg; Wirebox:33lbs/15kg
Mounting / Installation Angle
5
15 to 90 degrees from horizontal (vertical, or angled)
M8 Stud Type Terminal Block
(Wire range: #6-3/0AWG CU / AL, Lugs not supplied)
Screw Clamp, Neg. Busbar (RSD version
6
)
Wire range: #14 - #6AWG CU
RSD
6
and Standard Wire-box: 20A fuses provided
(Fuse values up to 30A acceptable)
Certifications and Standards
UL1741-SA Ed. 3, UL1699B, UL1998, CSA-C22.2 NO.107.1-01,
IEEE1547-2018, FCC PART15
IEEE 1547a2014, IEEE1547-2018, CA Rule 21, ISO-NE, HECO
Volt-RideThru, Freq-RideThru, Ramp-Rate, Specified-PF, Volt-
VAr, Freq-Watt, Volt-Watt
3)
Active Power Derating begins; at 40°C when PF=±0.9 and MPPT ≥Vmin, at 45°C when PF=1 and MPPT ≥Vmin, and at 50°C when PF=1 and
MPPT V ≥ 700Vdc.
4)
See user manual for further requirements regarding non-operating conditions.
5)
Shade Cover accessory required for installation angles of 75 degrees or less.
6)
RSD wire-box only includes fuses/fuseholders on the positive polarity, compliant with NEC 2017, 690.9 (C).
7)
Fuse values above 20A have additional spacing requirements or require the use of the Y-Comb Terminal Block. See user manual for details.
