59
Table 3-12 Specification of AC Breaker Selection
Inverter
Min AC OCPD
Max AC OCPD
CPS SCA50KTL-DO/US-480
50kVA = 80A
55kVA = 90A
110A
CPS SCA60KTL-DO/US-480
60kVA = 100A
66kVA = 100A
125A
CPS SCA36KTL-DO/US-480
60A
125A
3.4 Communication Connection
CPS SCA36/50/60KTL-DO/US-480 inverters support industry standard
Modbus RS485 communication.
Figure 3-31 Communication Board in the Wirebox
P1
P1
P8
485_GN
D
RS485
_B-
RS485
_A+
12VG
ND
+12V
P8
P6
S1
P7
P9
485_GND
RS485_B-
RS485_A+
12VGND
S1
+12V
P6
S1
P7
P9
1
2 3
4
5
