2.4 Smart Inverter Functions:

The CPS SCA36/50/60KTL-DO/US-480 3-Phase String Inverters employ Smart

Inverter (Grid Support) Functions in compliance with UL1741, SA8-SA18 and

UL1741-SB standards. The default activation status is indicated below.

Smart Inverter Function

IEEE1547-2018

Rule 21

ISO-NE

Anti-islanding

Enabled

Low/High Voltage Ride-

Through

Enabled

Low/High Frequency Ride-

Through

Enabled

Dynamic Volt/VAR Operation

Enabled

Disabled

Ramp Rate

Enabled

Fixed Power Factor

Enabled

Disabled

Reconnect by “Soft-Start”

Enabled

Frequency-Watt

Disabled

Enabled

Disabled

Volt/Watt

Enabled

Disabled
