24
SHADE COVER
>15
o
a.)
NO
SHADE COVER REQUIRED
b.) SHADE COVER REQUIRED
c.)
NOT
> 90° TILTED FORWARD
d.) NOT UPSIDE DOWN
Figure 3-2 Inverter Mounting Options
