CPS SCA36KTL-DO/US-480 - Page 35

28
14"
MIN
E)
BAFFLE MUST:
1. EXTEND 8” MIN. ABOVE AND BELOW FANS
2. EXTEND 4" MIN. PAST FRONT OF INVERTER
3. LOCATED 7" MIN. FROM BOTH INVERTERS
D)
WALL OR
PASSIVE
CABINET
12"
MIN
A)
12"
MIN
B)
C)
BAFFLE
8"
MIN
8"
MIN
BAFFLE
12"
MIN
12"
MIN
