Again, in the two possible configurations, that is, with REAR tensioners or with FRONT tensioners for the pulling
ropes
REAR rope tensioning FRONT rope tensioning
3) HYDRAULIC MOVEMENT
This type of movement, which is also available in the two possible configurations, that is, with REAR tensioners or
with FRONT tensioners for the pulling ropes, is mainly used
on agricultural vehicles where using pressurised oil to power the various accessories is more
common.
REAR rope tensioning FRONT rope tensioning
FRONT UNIT MAXIMUM CLEARANCE
PE = ELECTRIC Pre-assembled Unit SE = ELECTRIC Standard unit
PI = HYDRAULIC Pre-assembled Unit SI = HYDRAULIC Standard unit
PM = MANUAL Pre-assembled Unit SM = MANUAL Standard unit
