CABRIOLE’
CRAMARO TS S.r.l. – 37044 COLOGNA V.TA (VR) - VIA QUARI DESTRA, 71/G TEL. +39 0442/411688 / FAX + 39 0442/411690
E-MAIL info@cramaro.com WEBSITE: http://www.cramaro.com - Manual n° MCA016-EN-ED00 – date 15/01/15
page 25
FIG 33
FIG 32
In this case, either the ELECTRIC or MANUAL pulling unit is secured
directly to the front sideboard of the container, allowing the connection shaft to pass
between the RIGHT pulling pulley and the LEFT pulling pulley behind the cylinder itself, in a
position that does not interfere with it.
CURVED CAB-SHIELD
ELECTRIC VERSION
MANUAL VERSION
In other cases, the lifting cylinder is below the front level of the container; however, the container has NO CAB-
SHIELD and, therefore, once retracted, the tarpaulin would obstruct the container loading zone.
In this case, CRAMARO TS has developed and put into production a series of COMPOSITE CAB-SHIELDS,
adaptable to all the widths of containers on the market and with a FLAT central section
These elements are also made in hot-dip galvanised, folded sheet metal and house MANUAL or ELECTRIC
PULLING UNITS already fastened inside them.
