tighten the CABLE GLANDS - 12 V - - 24 V -
The control unit contains the following:
1 red “ MUSHROOM-SHAPED “ control panel emergency and activation button
( with REMOVABLE keys )
2 ) Knob to open the door that protects the control panel
3 Boss to protect electrical connections
Inside the cover of the control unit, instead, the control panel
contains the following :
4 Red warning light, on when the tarpaulin is moving
5 80 A fuse
6 Spring-loaded operating switch:
7 Identification plate for the
control unit featuring the SERIAL NUMBER (to be reported to Customer
Service).
8 Plate with WARNINGS FOR USE, indicating all the most important provisions to use the
tarpaulin
INTERNAL VIEW OF THE CONTROL PANEL
