CABRIOLE’
CRAMARO TS S.r.l. – 37044 COLOGNA V.TA (VR) - VIA QUARI DESTRA, 71/G TEL. +39 0442/411688 / FAX + 39 0442/411690
E-MAIL info@cramaro.com WEBSITE: http://www.cramaro.com - Manual n° MCA016-EN-ED00 – date 15/01/15
page 52
FIG 86
A
B
FIG 87 Pers
56
174
100
65
FIG 87
A
6 mm
- HORIZONTAL ROLLER HOOKS -
Made in the same way as the previous standard hooks,
they are supplied in a number of pairs based on the
length of the container and the location in which
the tarpaulin will mainly be used
There are TWO types of anchoring profiles available for
this type of hook,
A) with SEPARATE elements
B) with CONTINUOUS profile
TYPICAL HOOK CONFIGURATION AND SIZES
- IN-GROOVE HORIZONTAL ROLLER HOOKS FOR CONTAINERS WITH INTERNAL AISLE -
This type of hook was made especially for containers that already have a STANDARD internal GROOVE along the
upper edge of the sideboards .
Using this type of hook, you no longer need to apply anything to the sides of the container and tarpaulin stability is
guaranteed with nothing else.
The hooks are usually supplied in 3 or even 4 pairs per container.
HOOK DISTRIBUTION DIAGRAM
