CABRIOLE’
CRAMARO TS S.r.l. – 37044 COLOGNA V.TA (VR) - VIA QUARI DESTRA, 71/G TEL. +39 0442/411688 / FAX + 39 0442/411690
E-MAIL info@cramaro.com WEBSITE: http://www.cramaro.com - Manual n° MCA016-EN-ED00 – date 15/01/15
page 68
ø100 MM REAR RETURN PULLEY ASSEMBLY DIAGRAM
When assembling the rear plate, make sure that the pulley is positioned as shown in the
picture and make sure that the threaded ring nut is properly tightened.
