BevMax 4 5800-4/3800-4 Board Programming
Service Mode Test Mode Setup Mode 1 Setup Mode 2
A Step through below A Step through below A Step through below A Step through below
B Cash Box B List Errors B Enter Message B STS Enabled/Disabled
C Sales C Light Timer C Clear Message C Custom STS
D Display Temperature D Enable Snack Menus D Enable/Disable $ D Default STS
E Set Refrig. Temp. E Keypad Test E Set Happy Hour Time E Display STS
F Clear Totals F
*Factory Diagnostics
F Master Reset F Set No Vend Limit
1 Number Sold 1
Tube Fill/Dispense
1 Machine Number 1 Multivend
2 Enable Item (Disable) 2 Daylight Savings 2 Set Happy Hour 2 Select Language
3 Sales by Column 3 Set Not Available 3 Set Not Available Time 3 Sold Out Enable
4 Escrow 4 Set Credit Timer 4 Consumer Overpay 4 Price Display
5 Force Vend 5 Door Open 5
Date/Time
5 Storage Temp Enable
6 Set Temp. (F or C) 6 Power out 6 Total Sales 6 Interval Sales Reset
7 Set Prices (Regular &
Secondary
7 Test Health Guard 7 Health Control 7 Set Lights Off
8 ***Set Shelf Location (G, M1,
M2, D, E, E1, D2)
8 Display Health Guard 8 Update Software 8 Double Talk
9 Relay Toggle Test 9
**Test Vend
9 Set Lights Off Time 9 Set Storage Time
0 Clear Errors 0 Show Checksum 0 Enter New Password 0 Set Storage Temp
*Factory Diagnostics – sub-menus
A Build #### = software revision build number
B Model # = Set Model Number DN5800-4, DN3800-4, DN5800-E4, DN3800-E4
E Extended Cup = All BevMax 4 5800-4 - Enabled
F Delivery (Picker) Cup Sensor Option = BevMax 4 5800-4 with cup sensor set ON, BevMax 4 5800-4 with out cup sensor set OFF.
1 Position Test = F – goes home; 0 – cycles plunger; * - stops all motors; Shelf letter – moves cup to shelf selected; Column # - moves cup to column selected.
2 Port Test = A – opens port; B – closes port; C – sensor test ON’; D – sensor test OFF; E – cup LED’s on; F – port LED’s on; * - All Stop.
3 Delivery (Picker) Cup Check = “On (status of cup sensor):#”; “In (detects product in cup):#”; “Out (picker out switch status):#”; “Hm (picker home switch status):#”.
4
Repeat Vend
5 Vend Error Codes = Factory Use Only / Do Not Use.
6 Product Sensors = All BevMax 4 5800-4 set ON
7 Factory Use Only / Do Not Use
8 Shelf Offset = BevMax 4 5800-4 Shelf Location “D2” = 700
9 (Not Used)
0 Hook Swipe X = sets far right travel distance to Delivery door (BevMax 4 5800-4 factory default = 93871).
**Test Vend = Test Mode press “9” and “*” (enter) to get to “Enter Selection”. Close the service door and choose desired selection to test vend.
To set Timers for schools = Set Date/Time / Set Not Available blocks / Set Not Available Times / Set Daylight Savings Time
Cash and Sales Numbers = Sales / Number Sold / Sales by Column / Total Sales / Cash Box
***Set Shelf Location = Service Mode press “8” - BevMax 4 5800-4 = D2 – Domestic, E3 - Export 5 Shelf, E4 – Export 4 Shelf (default is 700)
Set Hook Swipe X = Test Mode press “F” and “*” (enter) to get to “Factory Diagnostics”. Press “8” and “*” (enter) to get to Hook Swipe ##### (default is 91871).
